ZA280CL | L-852CL LED 8″ Taxiway Centerline, Straight Sections (Narrow), High Intensity Lighting Solutions

Compliance and Applications

• FAA Certified: L-852CL (AC 150/5345-46)
• FAA Eng Brief No 67
• ICAO Annex 14. Vol 1
• IEC 61827
• EASA
• Stanag 3316 (NATO)

The ZA280CL is a high intensity, inset LED taxiway centerline (narrow straight sections) fixture with a narrow beam, suitable for CAT III all weather operation airfield ground lighting (agl) systems.

The fixture may be used in 6.6A airfield lighting circuits normally supplied from 1 x 45W, 1 x 65W or 100W isolating transformer.

Ordering Codes

ApplicationColor: A SideColor: B SideSpecificationConnections
80-ZA280CL: L-852CL Taxiway Centerline Straight (Narrow)G: Green
Y: Yellow
X: Blank
G: Green
Y: Yellow
X: Blank
1: FAA1: 1 Bi Pin Plug
Additional optional features are available upon request.

Packaging

• Net weight: 6.6 lb. (3Kg)
• Gross weight: 7.7 lb. (3.5Kg)
• Box: 9.1" (230mm) (w) x 9.1" (230mm) (d) x 5.7" (146mm) (h)
